QS260 13inch 1500W E-Scooter Hub Motor(30H) V1 Type

13inch 260 E-Scooter Hub Motor(30H) 1500W V1 Type   13inch 260 Hub Motor specially designed for electric motorcycle or electric scooters, the rated power can be made at 1500W,2000W,3000W or 5000W. Max speed can be customs at 35-100km/h.   Motor Specification:   Motor Type: BLDC Hub Motor with Permanent Magnet Motor design: Double axle out with 13inch rim Rim size:3.5×13 Matching Tire: 130/70-13 Magnet:30H of Pole Pairs: 23 pairs Rated Power: 1500W Max Power: 2500W Rated Voltage: 48V( 60V/72V Can be optional) Speed: 45km/h (30-55km/h can be customized) Max No-load RPM: 650RPM Max Torque: 140N.M Max Efficiency: 86% Continious current:36A Max current:50A Brake type: Disc brake Rear Fork width for installation: 200mm Winding Core material: Iron Cross Section of Phase wire: 6 mm2 Hall sensor phasing angle: 120 degree Temperature Sensor: Optional Working Temperature: 70 degree, Peak 120 degree Waterproof Grade: IP54 W./ G..W. : 21kgs / 22kgs Package Size: 44*43*41CM
