17inch 8000W In-Wheel Hub Motor V2 Type for Electric Motorcycle
17inch 273 E-Scooter In-Wheel Hub Motor(50H) 8000W V2 Type 17inch Hub Motor specially designed for electric motorcycle, the rated power can be made 2kw,3kw,4kw,5kw,6kw,7kw or 8kw. Max speed can be customized from 30-120KMPH. Motor Specification: Motor Type: BLDC Hub Motor with Permanent Magnets Motor design: Double axle out with 17inch Aluminium rim Rim size:3.5×17 Matching Tire: 120/70-17 Magnet Height: 50MM of Pole Pairs: 28 pairs Rated Power: 8000W Max Power:11250W(Peak 16000W) Rated Voltage: 72V( 72-144V Can be optional) Speed: 115km/h (30-120km/h can be customized) Max No-load RPM:1160RPM Max Torque: 200N.M Max Efficiency: 86% Continious current:130A Max current:190A ,Peak 260A Brake type: Disc brake Rear Fork width for installation: 200mm Winding Core material: Aluminium Cross Section of Phase wire: 16 mm2 Hall sensor phasing angle: 120 degree Temperature Sensor: Optional Working Temperature: 70 degree, Peak 120 degree Waterproof Grade: IP54 W./ G..W. : 22kgs / 23kgs Package Size: 58*58*40CM
